[EN] COUPLED HETEROARYL COMPOUNDS VIA REARRANGEMENT OF HALOGENATED HETEROAROMATICS FOLLOWED BY OXIDATIVE COUPLING (ACYL MOIETIES)<br/>[FR] COMPOSÉS HÉTÉROARYLÉS COUPLÉS PAR UN RÉARRANGEMENT D'HÉTÉROAROMATIQUES HALOGÉNÉS SUIVI PAR UN COUPLAGE OXYDANT (FRACTIONS ACYLE)
申请人:GEORGIA TECH RES INST
公开号:WO2013023106A1
公开(公告)日:2013-02-14
The inventions disclosed and described herein relate to new and efficient generic methods for making a wide variety of compounds having HAr - Z - Har tricyclic cores, wherein HAr is an optionally substituted five or six membered heteroaryl ring, and Hal is a halogen, and Z is a bridging radical, such as S, Se, NR5, C(O), C(O)C(O), Si(R5)2, SO, SO2, PR5, BR5, C(R5)2 or P(O)R5 and both HAr are covalently bound to one another. The synthetic methods employ a "Base-Catalyzed Halogen Dance" reaction to prepare a metallated compound comprising a five or six membered heteroaryl ring comprising a halogen atom, and then oxidatively coupling the reactive intermediate compound. The compounds of Formula (II) and/or oligomer or polymers comprising repeat units having Formula (II) can be useful for making semi-conducting materials, and/or electronic devices comprising those materials. Acyl compounds can be prepared. Heteroarylene substituents can be used. The tricyclic core can be coupled to itself. The Z group also can be strong electron-withdrawing groups such as C=C(CN)2 or [C=C(CN)2]2. Organic electronic devices can be made including field-effect transistors.
本公开的和描述的发明涉及制备具有HAr-Z-Har三环核的各种化合物的新型高效通用方法,其中HAr是可选择地取代的五元或六元杂环芳基环,Hal是卤素,Z是桥联基团,如S、Se、NR5、C(O)、C(O)C(O)、Si(R5)2、SO、SO2、PR5、BR5、C(R5)2或P(O)R5,且两个HAr均以共价键结合在一起。合成方法利用“碱催化卤素舞蹈”反应制备包含卤素原子的五元或六元杂环芳基环的金属化合物,然后氧化偶联反应中间体化合物。具有式(II)的化合物和/或包含具有式(II)重复单元的寡聚物或聚合物可用于制备半导体材料和/或包含该材料的电子器件。可以制备酰基化合物。可以使用杂芳基取代基。三环核可以与自身偶联。Z基也可以是强电子吸引基团,如C=C(CN)2或[C=C(CN)2]2。可以制备包括场效应晶体管在内的有机电子器件。
