2,2'-二萘醚 | 613-80-9

• 物质功能分类: 化学试剂 - 有机试剂 - 多环化合物
• 分子结构分类: 有机化合物 - 有机氧化合物
• 中文名称: 2,2'-二萘醚
• 中文别名: β,β'-二萘醚；2-萘醚；2,2'-二萘基醚；2,2ˊ-二萘醚；2,2"-二萘基醚；β,βˊ-二萘醚；2-萘醚
• 英文名称: 2,2'-Dinaphthyl ether
• 英文别名: 2,2'-oxybis-naphthalene；Di-2-naphthyl ether；2-naphthalen-2-yloxynaphthalene
• CAS: 613-80-9
• 化学式: C₂₀H₁₄O
• 分子量: 270.331
• InChiKey: DZRLNYVDCIYXPG-UHFFFAOYSA-N

物化性质

• 熔点：
  105°C
• 沸点：
  250 °C / 19mmHg
• 密度：
  1.0717 (rough estimate)
• 溶解度：
  可溶于DMSO（略微加热）、甲醇（略微加热）
• 稳定性/保质期：

  性质与稳定性：在常温常压下，该物质不会分解。

计算性质

• 辛醇/水分配系数(LogP)：
  6.3
• 重原子数：
  21
• 可旋转键数：
  2
• 环数：
  4.0
• sp3杂化的碳原子比例：
  0.0
• 拓扑面积：
  9.2
• 氢给体数：
  0
• 氢受体数：
  1

安全信息

• 安全说明：
  S22,S24/25
• 储存条件：
  贮存： 将密器密封后，放入密封的主藏器中，并存放在阴凉、干爽的地方。

SDS

---

SECTION 1: Identification of the substance/mixture and of the company/undertaking
Product identifiers
Product name : 2,2'-Oxydinaphthalene
REACH No. : A registration number is not available for this substance as the substance
or its uses are exempted from registration, the annual tonnage does not
require a registration or the registration is envisaged for a later
registration deadline.
Relevant identified uses of the substance or mixture and uses advised against
Identified uses : Laboratory chemicals, Manufacture of substances

---

SECTION 2: Hazards identification
Classification of the substance or mixture
Not a hazardous substance or mixture according to Regulation (EC) No. 1272/2008.
This substance is not classified as dangerous according to Directive 67/548/EEC.
Label elements
The product does not need to be labelled in accordance with EC directives or respective national laws.
Other hazards
This substance/mixture contains no components considered to be either persistent, bioaccumulative and
toxic (PBT), or very persistent and very bioaccumulative (vPvB) at levels of 0.1% or higher.

---

SECTION 3: Composition/information on ingredients
Substances
Molecular weight : 270,33 g/mol
No components need to be disclosed according to the applicable regulations.

---

SECTION 4: First aid measures
Description of first aid measures
General advice
Consult a physician. Show this safety data sheet to the doctor in attendance.
If inhaled
If breathed in, move person into fresh air. If not breathing, give artificial respiration. Consult a physician.
In case of skin contact
Wash off with soap and plenty of water. Consult a physician.
In case of eye contact
Flush eyes with water as a precaution.
If swallowed
Never give anything by mouth to an unconscious person. Rinse mouth with water. Consult a physician.
Most important symptoms and effects, both acute and delayed
The most important known symptoms and effects are described in the labelling (see section 2.2) and/or in
section 11
Indication of any immediate medical attention and special treatment needed
No data available

---

SECTION 5: Firefighting measures
Extinguishing media
Suitable extinguishing media
Use water spray, alcohol-resistant foam, dry chemical or carbon dioxide.
Special hazards arising from the substance or mixture
Nature of decomposition products not known.
Advice for firefighters
Wear self-contained breathing apparatus for firefighting if necessary.
Further information
No data available

---

SECTION 6: Accidental release measures
Personal precautions, protective equipment and emergency procedures
Use personal protective equipment. Avoid dust formation. Avoid breathing vapours, mist or gas. Avoid
breathing dust.
For personal protection see section 8.
Environmental precautions
Do not let product enter drains.
Methods and materials for containment and cleaning up
Pick up and arrange disposal without creating dust. Sweep up and shovel. Keep in suitable, closed
containers for disposal.
Reference to other sections
For disposal see section 13.

---

SECTION 7: Handling and storage
Precautions for safe handling
Avoid formation of dust and aerosols.
Provide appropriate exhaust ventilation at places where dust is formed.
For precautions see section 2.2.
Conditions for safe storage, including any incompatibilities
Store in cool place. Keep container tightly closed in a dry and well-ventilated place.
Storage class (TRGS 510): Non Combustible Solids
Specific end use(s)
Apart from the uses mentioned in section 1.2 no other specific uses are stipulated

---

SECTION 8: Exposure controls/personal protection
Control parameters
Components with workplace control parameters
Exposure controls
Appropriate engineering controls
Handle in accordance with good industrial hygiene and safety practice. Wash hands before breaks and
at the end of workday.
Personal protective equipment
Eye/face protection
Use equipment for eye protection tested and approved under appropriate government standards
such as NIOSH (US) or EN 166(EU).
Skin protection
Handle with gloves. Gloves must be inspected prior to use. Use proper glove removal technique
(without touching glove's outer surface) to avoid skin contact with this product. Dispose of
contaminated gloves after use in accordance with applicable laws and good laboratory practices.
Wash and dry hands.
The selected protective gloves have to satisfy the specifications of EU Directive 89/686/EEC and
the standard EN 374 derived from it.
Body Protection
Choose body protection in relation to its type, to the concentration and amount of dangerous
substances, and to the specific work-place., The type of protective equipment must be selected
according to the concentration and amount of the dangerous substance at the specific workplace.
Respiratory protection
Respiratory protection is not required. Where protection from nuisance levels of dusts are desired,
use type N95 (US) or type P1 (EN 143) dust masks. Use respirators and components tested and
approved under appropriate government standards such as NIOSH (US) or CEN (EU).
Control of environmental exposure
Do not let product enter drains.

---

SECTION 9: Physical and chemical properties
Information on basic physical and chemical properties
a) Appearance Form: solid
b) Odour No data available
c) Odour Threshold No data available
d) pH No data available
e) Melting point/freezing No data available
point
f) Initial boiling point and No data available
boiling range
g) Flash point No data available
h) Evaporation rate No data available
i) Flammability (solid, gas) No data available
j) Upper/lower No data available
flammability or
explosive limits
k) Vapour pressure No data available
l) Vapour density No data available
m) Relative density No data available
n) Water solubility No data available
o) Partition coefficient: n- No data available
octanol/water
p) Auto-ignition No data available
temperature
q) Decomposition No data available
temperature
r) Viscosity No data available
s) Explosive properties No data available
t) Oxidizing properties No data available
Other safety information
No data available

---

SECTION 10: Stability and reactivity
Reactivity
No data available
Chemical stability
Stable under recommended storage conditions.
Possibility of hazardous reactions
No data available
Conditions to avoid
No data available
Incompatible materials
Strong oxidizing agents
Hazardous decomposition products
In the event of fire: see section 5

---

SECTION 11: Toxicological information
Information on toxicological effects
Acute toxicity
No data available
Skin corrosion/irritation
No data available
Serious eye damage/eye irritation
No data available
Respiratory or skin sensitisation
No data available
Germ cell mutagenicity
No data available
Carcinogenicity
IARC: No component of this product present at levels greater than or equal to 0.1% is identified as
probable, possible or confirmed human carcinogen by IARC.
Reproductive toxicity
No data available
Specific target organ toxicity - single exposure
No data available
Specific target organ toxicity - repeated exposure
No data available
Aspiration hazard
No data available
Additional Information
RTECS: Not available
To the best of our knowledge, the chemical, physical, and toxicological properties have not been
thoroughly investigated.

---

SECTION 12: Ecological information
Toxicity
No data available
Persistence and degradability
No data available
Bioaccumulative potential
No data available
Mobility in soil
No data available
Results of PBT and vPvB assessment
This substance/mixture contains no components considered to be either persistent, bioaccumulative and
toxic (PBT), or very persistent and very bioaccumulative (vPvB) at levels of 0.1% or higher.
Other adverse effects
No data available

---

SECTION 13: Disposal considerations
Waste treatment methods
Product
Offer surplus and non-recyclable solutions to a licensed disposal company. Dissolve or mix the material
with a combustible solvent and burn in a chemical incinerator equipped with an afterburner and scrubber.
Contaminated packaging
Dispose of as unused product.

---

SECTION 14: Transport information
UN number
ADR/RID: - IMDG: - IATA: -
UN proper shipping name
ADR/RID: Not dangerous goods
IMDG: Not dangerous goods
IATA: Not dangerous goods
Transport hazard class(es)
ADR/RID: - IMDG: - IATA: -
Packaging group
ADR/RID: - IMDG: - IATA: -
Environmental hazards
ADR/RID: no IMDG Marine pollutant: no IATA: no
Special precautions for user
No data available

---

SECTION 15: Regulatory information
This safety datasheet complies with the requirements of Regulation (EC) No. 1907/2006.
Safety, health and environmental regulations/legislation specific for the substance or mixture
No data available
Chemical Safety Assessment
For this product a chemical safety assessment was not carried out

---

SECTION 16: Other information
Further information
Copyright 2014 Co. LLC. License granted to make unlimited paper copies for internal use
only.
The above information is believed to be correct but does not purport to be all inclusive and shall be
used only as a guide. The information in this document is based on the present state of our knowledge
and is applicable to the product with regard to appropriate safety precautions. It does not represent any
guarantee of the properties of the product. Corporation and its Affiliates shall not be held
liable for any damage resulting from handling or from contact with the above product. See
and/or the reverse side of invoice or packing slip for additional terms and conditions of sale.

制备方法与用途

溶解性于对甲苯：近乎透明

反应信息

• 作为反应物：
  描述：

  2,2'-二萘醚 在 三氯化铝 、 二氯化硫 作用下， 生成 Dibenzophenoxathiin
  参考文献：
  名称：

  Child; Smiles, Journal of the Chemical Society, 1926, p. 957

  摘要：

  DOI：
• 作为产物：
  描述：

  2-溴萘 在 potassium phosphate 、 (-)-1,2-双((2R,5R)-2,5-二甲基磷杂环戊烷)苯(1,5-环辛二烯)三氟甲磺酸铑(I) 、 [Ir(C₆H₂F₂-C₅H₃NCF₃)₂(4,4′-di-tert-butyl-2,2′-dipyridyl)] 、 水 作用下， 反应 36.0h， 以43%的产率得到2,2'-二萘醚
  参考文献：
  名称：

  二芳基醚形成合并光氧化还原和镍催化

  摘要：

  Photoredox 和 Ni 催化在温和条件下结合产生二芳基醚。在容易获得的有机光催化剂和 NiBr 2 (dtbpy)存在下，广泛的芳基卤化物和苯酚衍生物交叉偶联。对称二芳基醚也已在水存在下由芳基溴化物直接获得。机理研究支持在反应开始时 Ni(0) 物质的参与以及在生产性 C(sp 2 )-OAr 还原消除之前的 Ni(II)/Ni(III) 光催化单电子转移过程。

  DOI：

  10.1021/acs.organomet.1c00018

文献信息

• RESIST COMPOSITION, METHOD FOR FORMING RESIST PATTERN, POLYPHENOLIC COMPOUND FOR USE IN THE COMPOSITION, AND ALCOHOLIC COMPOUND THAT CAN BE DERIVED THEREFROM
  申请人：Mitsubishi Gas Chemical Company, Inc.

  公开号：US20160145231A1

  公开（公告）日：2016-05-26

  A resist composition containing a compound represented by the general formula (1) or (2), a method for forming a resist pattern using the composition, a polyphenolic compound for use in the composition, and an alcoholic compound that can be derived therefrom are described.

  描述了一种包含由通式（1）或（2）表示的化合物的光刻胶组合物，使用该组合物形成光刻胶图案的方法，用于该组合物的多酚化合物，以及可以由其衍生的醇化合物。
• Acid-catalyzed synthesis of condensed polycyclic diaryl ethers from arenols
  作者：Saori Tanii、Mieko Arisawa、Masahiko Yamaguchi

  DOI：10.1039/c9cc07172e

  日期：——

  Diaryl ethers containing condensed polycyclic aryl groups were synthesized from arenols in the presence of a catalytic amount of p-chlorobenzenesulfonic acid. Symmetrical binaphthyl, biphenanthryl, and bipyrenyl ethers were obtained in high yields. Unsymmetrical derivatives were also synthesized from 9-phenanthrol and arenols, using combinations of reactive and unreactive substrates.

  在催化量的对氯苯磺酸存在下，由芳烃合成含有稠合多环芳基的二芳基醚。以高收率获得对称的联萘，联菲和联苯醚。还使用反应性和非反应性底物的组合，从9-菲咯啉和芳烃合成不对称衍生物。
• Nickel-Catalyzed Homocoupling of Aryl Ethers with Magnesium Anthracene Reductant
  作者：Kosuke Higashida、Masaya Sawamura、Vishal Kumar Rawat

  DOI：10.1055/a-1509-5954

  日期：2021.9

  Nickel-catalyzed reductive homocoupling of aryl ethers has been achieved with Mg(anthracene)(thf)3 as a readily available low-cost reductant. DFT calculations provided a rationale for the specific efficiency of the diorganomagnesium-type two-electron reducing agent. The calculations show that the dianionic anthracene-9,10-diyl ligand reduces the two aryl ether substrates, resulting in the homocoupling

  已使用 Mg(蒽)(thf)3 作为容易获得的低成本还原剂实现了芳醚的镍催化还原均偶联。DFT 计算为二有机镁型双电子还原剂的特定效率提供了基本原理。计算表明，双阴离子蒽-9,10-二基配体还原了两个芳基醚底物，通过向Ni-Mg双金属体系提供电子导致均偶联反应形成有机镁镍(0)-ate配合物，从而导致两个连续的 C-O 键断裂反应。计算还表明路易斯酸性镁原子和富电子镍原子在 C-O 裂解反应中的协同作用。
• Base-Mediated N- and O-Arylations of NH-Containing Heterocycles, Heterocyclic Amines and Phenols
  作者：Zarrin Ghasemi、Nasim Shahi Shahrak、Behzad Jalali Roomi、Ziba Zakeri

  DOI：10.3184/174751915x14210808001753

  日期：2015.2

  Nucleophilic substitution reactions of N -heterocycles such as imidazole, benzimidazole, indole and pyrazole as well as NH₂ or OH containing heterocycles, with electron-deficient aryl halides in the presence of t-BuOK or K₂CO₃ as base and DMSO as solvent are reported. A series of N -aryl azoles, unsymmetric diaryl ethers and diaryl amines were obtained in good yields.

  报告了在以 t-BuOK 或 K2CO3 为碱和 DMSO 为溶剂的条件下，咪唑、苯并咪唑、吲哚和吡唑等 N -杂环以及含 NH2 或 OH 的杂环与缺电子芳基卤化物的亲核取代反应。结果以良好的收率获得了一系列 N 芳基唑、不对称二芳基醚和二芳基胺。
• [EN] NOVEL INTERMEDIATES FOR THE PREPARATION OF HMG-CoA REDUCTASE INHIBITORS<br/>[FR] NOUVEAUX INTERMÉDIAIRES POUR LA PRÉPARATION D'INHIBITEURS DE LA HMG-COA RÉDUCTASE
  申请人：RANBAXY LAB LTD

  公开号：WO2011132172A1

  公开（公告）日：2011-10-27

  The present invention provides a process for preparing novel intermediates of Formula wherein, R1 can be hydrogen, C1-C4 alkyl, halogen, nitro, hydroxy, or C1-C4 alkoxy; Rx can be selected from hydrophobic residue of HMG-CoA reductase inhibitors; which can be effectively used for the preparation of HMG-CoA reductase inhibitors such as rosuvastatin and pharmaceutically acceptable salts thereof.

  本发明提供了一种制备式中间体的方法，其中，R1可以是氢、C1-C4烷基、卤素、硝基、羟基或C1-C4烷氧基；Rx可以选择来自HMG-CoA还原酶抑制剂的疏水残基；该方法可以有效用于制备HMG-CoA还原酶抑制剂，如罗伐他汀及其药用盐。

表征谱图
