Metallacyclic complexes. Part 2. Synthesis of metallathietane-3,3-dioxide complexes of platinum(<scp>II</scp>) and palladium(<scp>II</scp>); the crystal structures of [Pt{CH(COPh)S(O)<sub>2</sub>CH(COPh)}(PPh<sub>3</sub>)<sub>2</sub>]·2CH<sub>2</sub>CI<sub>2</sub>and [Pd{CH(COPh)S(O)<sub>2</sub>CH(COPh)}(PMePh<sub>2</sub>)<sub>2</sub>]·CH<sub>2</sub>Cl<sub>2</sub>·H<sub>2</sub>O
作者:William Henderson、Raymond D. W. Kemmitt、Lesley J. S. Prouse、David R. Russell
DOI:10.1039/dt9890000259
日期:——
P(OPh)3; R = OMe, M = Pt or Pd, L = PPh3). Single-crystal X-ray diffraction studies have been carried out on [[graphic omitted]H(COPh)}(PPh3)2]·2CH2Cl2, [(6a)] and [[graphic omitted]H(COPh)}(PMePh2)2]·CH2Cl2·H2O [(6i)]. Crystals of (6a)·2CH2Cl2, are triclinic, space group P, Z= 2, in a unit cell with lattice parameters a= 20.835(2), b= 10.628(2), c= 12.577(4)Å, α= 109.6(1), β= 105.8(1), and γ= 91.4(l)°
配合物顺式-[PtCl 2 L 2 ]或反式-[PdCl 2 L 2 ](L =叔膦或亚磷酸三苯酯)与双(苯甲酰基甲基)砜或2,2'-磺酰基二乙酸的二甲酯和在回流的二氯甲烷中过量的氧化银(II)以高收率提供金属3,3-二氧杂环丁烷金属配合物[H(COR)} L 2 ](R = Ph,M = Pt或Pd, L = PPH 3,PMePh 2,PME 2 PH,PME 3,宠物3,或PBU ñ 3 ; M = PT,L = P(OPH)3; R = OMe,M = Pt或Pd,L = PPh 3)。在[[未图示] H(COPh)}(PPh 3)2 ]·2CH 2 Cl 2,[(6a)]和[[未图示] H(COPh)上进行了单晶X射线衍射研究。}(PMePh 2)2 ]·CH 2 Cl 2 ·H 2 O [(6i)]。在晶格参数为a = 20.835(2),b的晶胞中,(6a)·2CH 2 Cl
