双(对-甲苯磺酰)甲烷 | 15310-28-8

• 分子结构分类: 有机化合物 - 苯类化合物 - 苯和取代衍生物
• 中文名称: 双(对-甲苯磺酰)甲烷
• 中文别名: 双-(甲苯-4-磺酰)甲烷
• 英文名称: bis(4-methylphenylsulfonyl)methane
• 英文别名: methylene bis(toluene-4-sulfonate)；bis-(toluene-p-sulfonyl)methane；bis(p-tolylsulphonyl)methane；bis-(p-tolysulfonyl)methane；bis(tolylsulfonyl)methane；ditosylmethane；1-methyl-4-[(4-methylphenyl)sulfonylmethylsulfonyl]benzene
• CAS: 15310-28-8
• 化学式: C₁₅H₁₆O₄S₂
• mdl: MFCD00032255
• 分子量: 324.422
• InChiKey: XLOXYWLRAKCDQL-UHFFFAOYSA-N

物化性质

• 熔点：
  137-139℃
• 沸点：
  557.6±50.0 °C(Predicted)
• 密度：
  1.298±0.06 g/cm3(Predicted)
• 稳定性/保质期：
  常温常压下稳定，避免与氧化物接触。

计算性质

• 辛醇/水分配系数(LogP)：
  2.9
• 重原子数：
  21
• 可旋转键数：
  4
• 环数：
  2.0
• sp3杂化的碳原子比例：
  0.2
• 拓扑面积：
  85
• 氢给体数：
  0
• 氢受体数：
  4

安全信息

• 危险等级：
  IRRITANT
• 海关编码：
  2904100000
• 储存条件：
  常温下应密闭避光保存，并保持通风和干燥。

SDS

---

SECTION 1: Identification of the substance/mixture and of the company/undertaking
Product identifiers
Product name : Bis-(Toluene-4-Sulfonyl)Methane
: MNO000007
REACH No. : A registration number is not available for this substance as the substance
or its uses are exempted from registration, the annual tonnage does not
require a registration or the registration is envisaged for a later
registration deadline.

---

SECTION 2: Hazards identification
Classification of the substance or mixture
Classification according to Regulation (EC) No 1272/2008
Eye irritation (Category 2), H319
For the full text of the H-Statements mentioned in this Section, see Section 16.
Classification according to EU Directives 67/548/EEC or 1999/45/EC
Xi Irritant R36
For the full text of the R-phrases mentioned in this Section, see Section 16.
Label elements
Labelling according Regulation (EC) No 1272/2008
Pictogram
Signal word Warning
Hazard statement(s)
Causes serious eye irritation.
Precautionary statement(s)
P305 + P351 + P338 IF IN EYES: Rinse cautiously with water for several minutes. Remove
contact lenses, if present and easy to do. Continue rinsing.
Supplemental Hazard none
Statements
Other hazards
This substance/mixture contains no components considered to be either persistent, bioaccumulative and
toxic (PBT), or very persistent and very bioaccumulative (vPvB) at levels of 0.1% or higher.

---

SECTION 3: Composition/information on ingredients
Substances
Molecular weight : 324,42 g/mol
Hazardous ingredients according to Regulation (EC) No 1272/2008
Component Classification Concentration
Bis-(Toluene-4-Sulfonyl)Methane
Eye Irrit. 2; H319 <= 100 %
Hazardous ingredients according to Directive 1999/45/EC
Component Classification Concentration
Bis-(Toluene-4-Sulfonyl)Methane
Xi, R36 <= 100 %
For the full text of the H-Statements and R-Phrases mentioned in this Section, see Section 16

---

SECTION 4: First aid measures
Description of first aid measures
General advice
Consult a physician. Show this safety data sheet to the doctor in attendance.
If inhaled
If breathed in, move person into fresh air. If not breathing, give artificial respiration. Consult a physician.
In case of skin contact
Wash off with soap and plenty of water. Consult a physician.
In case of eye contact
Rinse thoroughly with plenty of water for at least 15 minutes and consult a physician.
If swallowed
Never give anything by mouth to an unconscious person. Rinse mouth with water. Consult a physician.
Most important symptoms and effects, both acute and delayed
The most important known symptoms and effects are described in the labelling (see section 2.2) and/or in
section 11
Indication of any immediate medical attention and special treatment needed
No data available

---

SECTION 5: Firefighting measures
Extinguishing media
Suitable extinguishing media
Use water spray, alcohol-resistant foam, dry chemical or carbon dioxide.
Special hazards arising from the substance or mixture
Nature of decomposition products not known.
Advice for firefighters
Wear self-contained breathing apparatus for firefighting if necessary.
Further information
No data available

---

SECTION 6: Accidental release measures
Personal precautions, protective equipment and emergency procedures
Use personal protective equipment. Avoid dust formation. Avoid breathing vapours, mist or gas. Ensure
adequate ventilation. Avoid breathing dust.
For personal protection see section 8.
Environmental precautions
Do not let product enter drains.
Methods and materials for containment and cleaning up
Pick up and arrange disposal without creating dust. Sweep up and shovel. Keep in suitable, closed
containers for disposal.
Reference to other sections
For disposal see section 13.

---

SECTION 7: Handling and storage
Precautions for safe handling
Avoid contact with skin and eyes. Avoid formation of dust and aerosols.
Provide appropriate exhaust ventilation at places where dust is formed.
For precautions see section 2.2.
Conditions for safe storage, including any incompatibilities
Store in cool place. Keep container tightly closed in a dry and well-ventilated place.
Storage class (TRGS 510): Non Combustible Solids
Specific end use(s)
Apart from the uses mentioned in section 1.2 no other specific uses are stipulated

---

SECTION 8: Exposure controls/personal protection
Control parameters
Components with workplace control parameters
Exposure controls
Appropriate engineering controls
Handle in accordance with good industrial hygiene and safety practice. Wash hands before breaks and
at the end of workday.
Personal protective equipment
Eye/face protection
Safety glasses with side-shields conforming to EN166 Use equipment for eye protection tested
and approved under appropriate government standards such as NIOSH (US) or EN 166(EU).
Skin protection
Handle with gloves. Gloves must be inspected prior to use. Use proper glove removal technique
(without touching glove's outer surface) to avoid skin contact with this product. Dispose of
contaminated gloves after use in accordance with applicable laws and good laboratory practices.
Wash and dry hands.
The selected protective gloves have to satisfy the specifications of EU Directive 89/686/EEC and
the standard EN 374 derived from it.
Body Protection
impervious clothing, The type of protective equipment must be selected according to the
concentration and amount of the dangerous substance at the specific workplace.
Respiratory protection
For nuisance exposures use type P95 (US) or type P1 (EU EN 143) particle respirator.For higher
level protection use type OV/AG/P99 (US) or type ABEK-P2 (EU EN 143) respirator cartridges.
Use respirators and components tested and approved under appropriate government standards
such as NIOSH (US) or CEN (EU).
Control of environmental exposure
Do not let product enter drains.

---

SECTION 9: Physical and chemical properties
Information on basic physical and chemical properties
a) Appearance Form: solid
b) Odour No data available
c) Odour Threshold No data available
d) pH No data available
e) Melting point/freezing No data available
point
f) Initial boiling point and No data available
boiling range
g) Flash point No data available
h) Evaporation rate No data available
i) Flammability (solid, gas) No data available
j) Upper/lower No data available
flammability or
explosive limits
k) Vapour pressure No data available
l) Vapour density No data available
m) Relative density No data available
n) Water solubility No data available
o) Partition coefficient: n- No data available
octanol/water
p) Auto-ignition No data available
temperature
q) Decomposition No data available
temperature
r) Viscosity No data available
s) Explosive properties No data available
t) Oxidizing properties No data available
Other safety information
No data available

---

SECTION 10: Stability and reactivity
Reactivity
No data available
Chemical stability
Stable under recommended storage conditions.
Possibility of hazardous reactions
No data available
Conditions to avoid
No data available
Incompatible materials
Strong oxidizing agents
Hazardous decomposition products
In the event of fire: see section 5

---

SECTION 11: Toxicological information
Information on toxicological effects
Acute toxicity
No data available
Skin corrosion/irritation
No data available
Serious eye damage/eye irritation
No data available
Respiratory or skin sensitisation
No data available
Germ cell mutagenicity
No data available
Carcinogenicity
IARC: No component of this product present at levels greater than or equal to 0.1% is identified as
probable, possible or confirmed human carcinogen by IARC.
Reproductive toxicity
No data available
Specific target organ toxicity - single exposure
No data available
Specific target organ toxicity - repeated exposure
No data available
Aspiration hazard
No data available
Additional Information
RTECS: Not available
To the best of our knowledge, the chemical, physical, and toxicological properties have not been
thoroughly investigated.

---

SECTION 12: Ecological information
Toxicity
No data available
Persistence and degradability
No data available
Bioaccumulative potential
No data available
Mobility in soil
No data available
Results of PBT and vPvB assessment
This substance/mixture contains no components considered to be either persistent, bioaccumulative and
toxic (PBT), or very persistent and very bioaccumulative (vPvB) at levels of 0.1% or higher.
Other adverse effects
No data available

---

SECTION 13: Disposal considerations
Waste treatment methods
Product
Dissolve or mix the material with a combustible solvent and burn in a chemical incinerator equipped with
an afterburner and scrubber. Offer surplus and non-recyclable solutions to a licensed disposal company.
Contaminated packaging
Dispose of as unused product.

---

SECTION 14: Transport information
UN number
ADR/RID: - IMDG: - IATA: -
UN proper shipping name
ADR/RID: Not dangerous goods
IMDG: Not dangerous goods
IATA: Not dangerous goods
Transport hazard class(es)
ADR/RID: - IMDG: - IATA: -
Packaging group
ADR/RID: - IMDG: - IATA: -
Environmental hazards
ADR/RID: no IMDG Marine pollutant: no IATA: no
Special precautions for user
No data available

---

SECTION 15: Regulatory information
This safety datasheet complies with the requirements of Regulation (EC) No. 1907/2006.
Safety, health and environmental regulations/legislation specific for the substance or mixture
No data available
Chemical Safety Assessment

---

SECTION 16 - ADDITIONAL INFORMATION
N/A

反应信息

• 作为反应物：
  描述：

  双(对-甲苯磺酰)甲烷 在 sodium hydroxide 、 sodium hypochlorite 作用下， 生成 chlorobis(toluene-4-sulfonyl)methane
  参考文献：
  名称：

  Dubenko,R.G. et al., Journal of Organic Chemistry USSR (English Translation), 1968, vol. 4, p. 315 - 319

  摘要：

  DOI：
• 作为产物：
  描述：

  bis(p-tolylthio)methane 在 双氧水 、 乙酸酐 、 溶剂黄146 作用下， 反应 26.0h， 生成 双(对-甲苯磺酰)甲烷
  参考文献：
  名称：

  钯催化脱羧烯丙基化和级联氧化环化从碳酸乙烯乙烯酯一锅法合成环戊烯醇

  摘要：

  从乙烯基碳酸乙烯酯和双磺酰甲烷开始，已经完成了一种用于合成高度官能化的环戊烯醇的有效的一锅法。该协议通过顺序钯催化脱羧烯丙基化和氧化环化以操作简单的方式进行。广泛的底物可以很好地适应各种环戊烯醇，以中等至良好的产率和优异的选择性。进一步的对照实验表明，可分离的 ( Z )-烯丙醇（高达Z / E = >19:1）的选择性形成是后续级联氧化环化成功的基础。

  DOI：

  10.1246/bcsj.20210451
• 作为试剂：
  描述：

  三苯乙烯 在 甲醇 、 dirhodium tetraacetate 、 双(对-甲苯磺酰)甲烷 、 臭氧 作用下， 以 二氯甲烷 、 乙腈 为溶剂， 反应 59.0h， 生成 2-[Bis-(4-methylphenyl)sulfonylmethyl]benzaldehyde
  参考文献：
  名称：

  双（磺酰基）甲基插入链烯基与苯基碳氢键在双（磺酰基）碘鎓与高度苯基化乙烯的反应中

  摘要：

  双（磺酰基）碘鎓叶立德 α-γ 与三苯基乙烯 (2a) 和四苯基乙烯 (2b) 的反应提供了插入底物的烯基和苯基碳氢键的产物。机械上令人困惑的特征是双（磺酰基）碘鎓叶立德与苯基化烯烃反应的反应模式中显示的多样性。(© Wiley-VCH Verlag GmbH & Co. KGaA, 69451 Weinheim, Germany, 2003)

  DOI：

  10.1002/ejoc.200390156

文献信息

• Novel sulfonyldiazomethanes, photoacid generators, resist compositions, and patterning process
  申请人：——

  公开号：US20040167322A1

  公开（公告）日：2004-08-26

  A chemical amplification type resist composition comprising a specific benzenesulfonyldiazomethane containing a long-chain alkoxyl group at the 2-position on benzene ring has many advantages including improved resolution, improved focus latitude, minimized line width variation or shape degradation even on long-term PED, minimized debris left after coating, development and peeling, and improved pattern profile after development and is thus suited for microfabrication.

  一种化学放大型抗蚀组合物，包括在苯环上的2-位含有长链烷氧基基团的特定苯磺酰二氮甲烷，具有许多优点，包括提高分辨率，改善焦点宽度，即使在长期PED上也减少线宽变化或形状退化，涂层、显影和剥离后减少残留物，并在显影后改善图案轮廓，因此适用于微加工。
• COMPOUND, RESIN, MATERIAL FOR FORMING UNDERLAYER FILM FOR LITHOGRAPHY, UNDERLAYER FILM FOR LITHOGRAPHY, PATTERN FORMING METHOD, AND METHOD FOR PURIFYING THE COMPOUND OR RESIN
  申请人：Mitsubishi Gas Chemical Company, Inc.

  公开号：US20170073288A1

  公开（公告）日：2017-03-16

  The compound according to the present invention is represented by a specific formula. The compound according to the present invention has a structure according to the specific formula, and therefore can be applied to a wet process and is excellent in heat resistance and etching resistance. In addition, the compound according to the present invention has such a specific structure, and therefore has a high heat resistance, a relatively high carbon concentration, a relatively low oxygen concentration and also a high solvent solubility. Therefore, the compound according to the present invention can be used to form an underlayer film whose degradation is suppressed at high-temperature baking and which is also excellent in etching resistance to oxygen plasma etching or the like. Furthermore, the compound is also excellent in adhesiveness with a resist layer and therefore can form an excellent resist pattern.

  根据本发明，该化合物由特定的公式表示。根据本发明，该化合物具有特定公式的结构，因此可应用于湿法工艺，具有优异的耐热性和耐蚀性。此外，根据本发明，该化合物具有特定结构，因此具有高耐热性、相对较高的碳浓度、相对较低的氧浓度以及高溶剂溶解性。因此，根据本发明的化合物可用于形成在高温烘烤时降解受抑制且在氧等离子体蚀刻中具有优异耐蚀性的底层膜。此外，该化合物在与光阻层的粘附性方面也表现出色，因此可形成优异的光阻图案。
• Photoacid generators, chemically amplified resist compositions, and patterning process
  申请人：Ohsawa Youichi

  公开号：US20070292768A1

  公开（公告）日：2007-12-20

  A photoacid generator has formula (1). A chemically amplified resist composition comprising the photoacid generator has advantages including a high resolution, focus latitude, long-term PED dimensional stability, and a satisfactory pattern profile shape. When the photoacid generator is combined with a resin having acid labile groups other than those of the acetal type, resolution and top loss are improved. The composition is suited for deep UV lithography.

  一种光酸发生剂的化学式为（1）。包括该光酸发生剂的化学增感抗蚀组合物具有诸如高分辨率、焦点宽度、长期PED尺寸稳定性和令人满意的图案轮廓形状等优点。当该光酸发生剂与具有除了缩醛类型以外的酸敏感基团的树脂结合时，可以改善分辨率和顶部损失。该组合物适用于深紫外光刻。
• POSITIVE RESIST COMPOSITION AND PATTERNING PROCESS
  申请人：NISHI Tsunehiro

  公开号：US20100062374A1

  公开（公告）日：2010-03-11

  A positive resist composition comprises (A) a resin component which becomes soluble in an alkaline developer under the action of an acid and (B) an acid generator. The resin (A) is a polymer comprising recurring units containing a non-leaving hydroxyl group represented by formula (1) wherein R 1 is H, methyl or trifluoromethyl, X is a single bond or methylene, m is 1 or 2, and the hydroxyl group attaches to a secondary carbon atom. The composition is improved in resolution when processed by lithography.

  一种正性光刻胶组合物包括（A）在酸的作用下在碱性显影剂中变得可溶的树脂组分和（B）酸发生剂。树脂（A）是一种聚合物，包含由式（1）表示的非离去羟基的重复单元，其中R1为H、甲基或三氟甲基，X为单键或亚甲基，m为1或2，并且羟基连接到次级碳原子。当通过光刻工艺处理时，该组合物在分辨率方面得到改善。
• Novel tertiary (meth)acrylates having lactone structure, polymers, resist compositions and patterning process
  申请人：Watanabe Takeru

  公开号：US20050250924A1

  公开（公告）日：2005-11-10

  Novel tertiary (meth)acrylate compounds having a lactone structure are polymerizable into polymers having improved transparency, especially at the exposure wavelength of an excimer laser and dry etching resistance. Resist compositions comprising the polymers are sensitive to high-energy radiation, have a high resolution, and lend themselves to micropatterning with electron beams or deep-UV rays.

  新型含有内酯结构的三元（甲基）丙烯酸酯化合物可聚合成具有改善透明度的聚合物，特别是在准分子激光的照射波长下以及干法刻蚀抗性方面。包括这些聚合物的抗蚀组合物对高能辐射敏感，具有高分辨率，并适用于电子束或深紫外线微图案化。

表征谱图
