[EN] LAUNDRY CARE COMPOSITION COMPRISING CARBOXYLATE DYE<br/>[FR] COMPOSITION D'ENTRETIEN DU LINGE COMPRENANT UN COLORANT CARBOXYLATE
申请人:PROCTER & GAMBLE
公开号:WO2015041814A1
公开(公告)日:2015-03-26
The present invention relates to a laundry care composition comprising from 0.00001 wt% to 0.5 wt% thiophene azo carboxylate dye having the structure of Formula I: (Formula I), wherein D1 is a thiophene group; wherein D2 is a carbocylic phenylene; wherein the two N atoms shown in Formula I bound directly to the carbocyclic phenylene are in a para-substitution to one another; wherein R1 is independently selected from [(CH2CR'HO)x(CH2CR"HO)y((CH2)wNH)zQ], C1-12 alkyl, C6-10 aryl, or C7-C22 aryl alkyl; wherein R2 is [(CH2CR'HO)x'(CH2CR"HO)y'((CH2)w'NH)z'Q]; wherein the sum of x + y + x' + y' is in the range of from 0 to 50; wherein x is an integer from 0 to 50; wherein x' is an integer from 0 to 50; wherein y is an integer from 0 to 50; wherein y' is an integer from 0 to 50; wherein w and w' are integers independently selected from 2 and 3; wherein z and z' are integers independently selected from 0 and 1; wherein R' and R" are each independently selected from the group consisting of H, C1-C4 alkyl, CH2O(CH2CH2O)a((CH2)bNH)dQ, phenyl and CH2OR5; wherein each R5 is independently selected from the group consisting of C1-C16 linear or branched alkyl, C6-C14 aryl, and C7-C16 arylalkyl; wherein each a is an integer independently selected from 0 to 2; wherein each b is an integer independently selected from 2 to 3; wherein each d is an integer independently selected from 0 to 1; wherein each Q is independently selected from the group consisting of H and Y, preferably all Q groups are independently selected Y groups; wherein each Y is an independently selected organic radical represented by Formula II (Formula II), wherein independently for each Y group: M is H or a charge balancing cation; m is an integer selected from 0 to 5, preferably 0, 1, 2 or 3, more preferably 0 or 1; n is an integer selected from 0 to 5, preferably 0, 1, 2 or 3, more preferably 0 or 1; the sum of m + n is in the range of from 1 to 10, preferably 1, 2 or 3, more preferably 1 or 2; and each R8 is independently selected from the group consisting of H, C3-18 or C4-C18 linear or branched alkyl, and C3-18 or C4-C18 linear or branched alkenyl; at least one R8 group is not H; wherein the sum of z + z' + d is at least 1; characterized in that the dye comprises at least one Q group that is Y and is either: (a) bound to a N atom in an R1 group wherein the index z is 1; or (b) bound to a N atom in an R2 group wherein the index z' is 1; or (c) bound to a N atom in an R' or R" group wherein the index d is 1.
本发明涉及一种洗涤护理组合物,其中含有从0.00001重量%到0.5重量%的噻吩偶氮羧酸酯染料,其具有以下结构的公式I:(公式I),其中D1是一个噻吩基团;其中D2是一个碳环苯基;在公式I中所示的两个N原子直接与碳环苯基结合,彼此之间处于对位取代;其中R1独立地选自[(CH2CR'HO)x(CH2CR"HO)y((CH2)wNH)zQ]、C1-12烷基、C6-10芳基或C7-C22芳基烷基;其中R2是[(CH2CR'HO)x'(CH2CR"HO)y'((CH2)w'NH)z'Q];其中x + y + x' + y'的总和在0至50的范围内;其中x是从0到50的整数;其中x'是从0到50的整数;其中y是从0到50的整数;其中y'是从0到50的整数;其中w和w'是独立选择的整数,取自2和3;其中z和z'是独立选择的整数,取自0和1;其中R'和R"各自独立地选自H、C1-C4烷基、CH2O(CH2CH2O)a((CH2)bNH)dQ、苯基和CH2OR5的群;其中每个R5独立地选自C1-C16直链或支链烷基、C6-C14芳基和C7-C16芳基烷基的群;其中每个a是独立选择的整数,取自0到2;其中每个b是独立选择的整数,取自2到3;其中每个d是独立选择的整数,取自0到1;其中每个Q是独立选择的,取自H和Y的群,最好所有Q群都是独立选择的Y群;其中每个Y是由公式II代表的独立选择的有机基团(公式II),对于每个Y群:M是H或一个电荷平衡阳离子;m是从0到5中选择的整数,最好为0、1、2或3,更好地为0或1;n是从0到5中选择的整数,最好为0、1、2或3,更好地为0或1;m + n的总和在1到10的范围内,最好为1、2或3,更好地为1或2;每个R8独立地选自H、C3-18或C4-C18直链或支链烷基,以及C3-18或C4-C18直链或支链烯基;至少一个R8群不是H;其中z + z' + d的总和至少为1;其特征在于染料包含至少一个Q群,该Q群是Y并且是以下情况之一:(a)与R1群中的N原子结合,其中指数z为1;或(b)与R2群中的N原子结合,其中指数z'为1;或(c)与R'或R"群中的N原子结合,其中指数d为1。
