POROUS ZEOLITE OF ORGANOSILICON, A METHOD FOR PREPARING THE SAME AND THE USE OF THE SAME
申请人:Gao Huanxin
公开号:US20090247776A1
公开(公告)日:2009-10-01
The present invention relates to an organosilicon porous zeolite, preparation of the same, and use of the same. The organosilicon porous zeolite of the invention has the following composition on molar basis: (1/n)Al
2
O
3
:SiO
(2-m/2)
:mR:xM, wherein n=5 to 1000, m=0.001 to 1, x=0.005 to 2, R is at least one selected from the group consisting of alkyl, alkenyl and phenyl and connected to a silicon atom in the framework of the zeolite, and M is an organic amine templating agent, wherein a solid Si
29
NMR spectrum of the zeolite has at least one Si
29
nuclear magnetic resonance peak in the range of from −80 to +50 ppm, and wherein a X-ray diffraction pattern of the zeolite exhibits diffraction peaks corresponding to d-spacing of 12.4±0.2, 11.0±0.3, 9.3±0.3, 6.8±0.2, 6.1±0.2, 5.5±0.2, 4.4±0.2, 4.0±0.2 and 3.4±0.1 Å. The porous zeolite can be used as an adsorbent or as a component of a catalyst for the conversion of an organic compound.
